Insulation Piercing Connector KWEP-CT
KWEP-CT
Quantity:
CONWELL Insulation Piercing Connectors (IPC)
High-performance CONWELL insulation piercing connectors (IPC) for LV ABC & bare conductors. EN50483 compliant, no-stripping design, and shear-head bolt technology for fast, maintenance-free power distribution.
| Model | KWEP-CT |
| Main Line Section | 1.6-95mm² |
| Branch Line Section | 1.5-16mm² |
| Torque | 10Nm |
| Nominal Current | 65A |
Why Choose CONWELL IPC?
Stripping-Free Installation – Piercing technology enables instant connection without cutting insulation, preserving conductor integrity and preventing oxidation.
EN50483 Certified – Meets European standards for safety, mechanical strength, and electrical stability.
Precision Shear-Head Bolt – Breaks off at preset torque to ensure optimal contact pressure, preventing over-tightening or loose connections.
Extreme Weather Resistance – UV-stabilized polymer body withstands salt spray, humidity, and temperature extremes.
Maintenance-Free Performance – Airtight, waterproof seal prevents corrosion, delivering 10+ years of service life.
